3.2m/10.5feet Truck Refrigeration Units(-20℃)-400FS

> Voltage: AC220V, 1PH, 2KW/AC380V, 3PH, 2.2KW
> Motor Power: 220V-2KW/380V-2KW
> Application: 7m³-14m³(-20℃ )
> Installation: Front Mounted
Standby Refrigeration Unit TKT-400FS
TKT-400FS truck refrigeration unit is specialized for small refrigerated truck body to keep frozen, powered by the engine of the vehicle, and standby unit. It has great advantages in Fuel Saving, Environmental and Highly Efficient.

※Exclusive Design for Refrigerated Truck Body Up to 7-14 m3 (-20 ℃) to Keep Frozen;
※Stream Line Design to Apply All Kinds of Truck Body;
※Big Cooling Capacity & Reliable Performance to Stand Against Hot & Dusty Climatic Condition;
※Easy Installation & Operation;
※Environment Friendly;
※18 Months Warranty Time After Delivery;





MAIN FEATURES OF TKT TRUCK REFRIGERATION UNITS
  • Really powerful Cooling Capacity, Large Air flow Capacity.
  • Green and Environment-friendly.
  • Famous World Top key components & Best raw materials.
  • Easy to Install and Operate.
  • Certificated by Various High Standard in US and Europe (CE, RHS etc. Certificate).
  • The high quality of the product guarantees its long life.
  • Excellent and considerate After-sales service (18 Months Warranty Time After Delivery;24/7     Service time)
  • Reasonable price.
  • Stylish and intimate design
  • Low current, High-Low voltage protection


Technological Data:
Model TKT-400FS
 Driven Type   Engine Driven + Standby Unit
 Installation   Front Mounted
 Voltage   Standby   AC220V,50Hz(60Hz),1PH / AC380V,50Hz,3PH
 Engine Driven   DC12V / 24V
 Compressor(Engine Driven)   Jap SD5S14(138cc)
 Compressor(Standby Unit)   Jap SD7L13
 Controller   Digital, In Cab, Made In Korea
 Engine Cooling Capacity   -20℃-1804 W/6150 BTU
 0℃-3666 W/12500 BTU
 Standby Unit   Motor Power   220V - 2KW
 380V - 2KW
 Peak Current   220V - 14A
 380V - 10A
Running Current 220V - 12A
380V - 9A
Cooling -20℃-1800 W/6138 BTU
0℃-5058W/17361 BTU
Volume of Container 7CBM-14CBM(-20℃ )
Refrigerant HFC-R404A,1.4kg
Condenser Coil Copper Tube / Aluminum Fin
Fan No. 1
Dimension 1213*483*233mm
Evaporator Coil Copper Tube / Aluminum Fin
Blower No. 2
Air Flow 1160m³/h
Dimension 1006*590*188 mm
Product material:
The materials used in all TKT products are internationally renowned brands. We choose suppliers from all over the world and work with the world's top brands such as Bitzer, Bock, Danfoss, Sanden, Valeo, Alco and Goodyear.
patent certificates:
Our products have patent certificates for appearance and cores. Our cores are made of copper tubes and aluminum fins, which will make the products last longer. It is different from the parallel flow products in the market. Reduce after-sales problems for you.

STRUCTURE
Structure of Truck Refrigeration Units
  • Evaporator Assembly;
  • Condenser Assembly
  • Compressor
  • In Cab Digital Controller
  • Motor(Stand by unit)
  • Other major components, such as Hoses Pipes, Wire Harness, Installation Accessories.

Inside Components
  • Evaporator Assembly; Condenser Assembly; Compressor; Digital Controller; Motor; Hoses Pipes, Wire Harness, Installation Accessories.

OEM/ODM Process
During the passed 24 years, TKT grows to the 100% OEM choice in China, for both bus A/C and truck refrigeration units, such as Yutong, Nanjing Golden Dragon, Xiamen Golden Dragon ect (Bus A/C), CIMC, Xinfei, Hongyu ect (Truck Refrigeration units). For the international market, TKT is the OEM for TATA Motors, TATA Marcopolo Motors, Daewoo ect, and exported to more than 85 countries with sales and service center.

If you are interested in working with TKT, please feel free to contact us.
