TKT Electric Parking A/C

Application: Truck, Van, Tractor, Mining Machine, Motor Home, Caravan, Houseboat, etc. Parking A/C means the air conditioner still able to cooling when vehicle engine is off, also called battery driven air conditioner and electric air conditioner.
> OEM/ODM/Customized Available
> Word Leader Manufacture of Bus A/C & Truck Refrigeration Units
> TS 16949/ISO9001 2015/ISO 14001 Quality Control Certification
TKT Electric Parking A/C Introduction:

Parking A/C means the air conditioner still able to cooling when vehicle engine is off, also called battery driven air conditioner and electric air conditioner. Normally it is designed for clients who want to use air conditioner when their vehicle parked in stationary. It can be applied widely on truck cabin, trailer, farming machine, construction machine, caravan, etc.


Major Technical Data:

Electric Parking A/C 20ER-3KW
          Cooling Capacity: 3KW(10230BTU)
         Voltage: DC12V/24V/48V/72/96V
          Application: Trailer, Truck, Van, Tractor, Mining                        Machine, Motor Home, Caravan, Houseboat, etc.
          Dimension: 700*750*205mm
Electric Parking A/C 50ER-5KW
           Cooling Capacity: 5KW(17050BTU)
         Voltage: DC12V/24V/48V/72/96V
         Application: Trailer, Truck, Van, Tractor, Mining                       Machine, Motor Home, Caravan, Houseboat, etc.
         Dimension: 700*750*205mm
Electric Parking A/C Split-3KW
         Cooling Capacity: 3KW(10230BTU)
         Voltage: DC12V/24V/48V/72/96V
         Application: Trailer, Truck, Van, Tractor, Mining                       Machine, Motor Home, Caravan, Houseboat, etc.
         Dimension: 700*750*205mm
Electric Parking A/C Split-5KW
         Cooling Capacity: 5KW(17050BTU)
         Voltage: DC12V/24V/48V/72/96V
         Application: Trailer, Truck, Van, Tractor, Mining                       Machine, Motor Home, Caravan, Houseboat, etc.
         Dimension: 700*750*205mm

If you do not know how to choose, please contact us.  We will provide you with the most professional service.

Specification Table:


Model No. TKT-20ER TKT-50ER TKT-20ES TKT-50ES
Structure Roof Top Model Split Model
Cooling Capacity 3000W / 10230 BTU 5000W / 17000 BTU 3000W / 10230 BTU 5000W / 17000 BTU
Compressor Electrical Compressor 21cc Electrical Compressor 26cc Electrical Compressor 21cc Electrical Compressor 26cc
Voltage DC12V/24V
Standard total current DC12V/60A; DC24V/30A DC12V/90A; DC24V/45A DC12V/60A; DC24V/30A DC12V/90A; DC24V/45A
Condenser QTY of Condenser Fan, 2 PCs QTY of Condenser Fan, 1 PCs
Condenser Air Flow, 2000M3/H Condenser Air Flow, 1500M3/H
Evaporator QTY of Evaporator Blower, 1 PC
Evaporator Air Flow, 1000M3/H
Refrigerant R134A, 600g
Dimension of Roof Top Unit 700*750*205mm (L*W*H) 728*522*200mm (L*W*H)
Application Truck cab, trailer, caravan, farming machine, construction machine, caravan, etc


TKT parking air conditioner has roof top self contained design and split design.

TKT-20ER and TKT-50ER model are self-contained rooftop parking cooler, one piece design make it easy for installation, 3KW/5KW cooling capacity option meet different cooling requirement! The standard voltage is DC12V/24V.(DC48V, DC72V, DC96V can be customized).

TKT-20ES and TKT-50ES model are self-contained rooftop parking cooler, split design: condenser can be back wall mounted( or rooftop mounted), digital controlled evaporator installed inside of truck cabin. 3KW/5KW cooling capacity option meet different cooling requirement! The standard voltage is DC12V/24V.(DC48V, DC72V, DC96V can be customized).


TKT Parking A/C Main Features
TKT Parking A/C Main Features:

▲ZERO CO2 Emission, truly environment-friendly; Zero fuel consumption helps driver reduce cost : for example, if driver use ac 6 hour s per day, 200 days per year, fuel consumption per hour is 3.5L/h, fuel price: 0.9USD, then the reduced cost is: 6*200*3.5*0.9=$ 3780
▲Security of a comfortable rest : the truck’s driver can rest in a healthy climate and safe cabin
▲Much safety on the roads : as stress and tiredness are reduced, also less risks during drive time
▲ 18 Months Free Warranty for Whole units
▲3 Years Free Warranty for Electric Compressor;
▲Sales and Service Center Cover more than 85 countries to provide 7*24 hours technical support;




TKT Parking A/C Design Introduction
TKT Parking A/C Design Introduction:

Parking A/C
Structure:

Condenser assembly, evaporator assembly, electric compressor assembly, and other components( all integrated in rooftop units)
Main parts: compressor, control panel, remote controller, expansion valve, etc.



TKT Parking A/C Design Advantage:
Self-contained rooftop one piece design, refrigerant already be filled, even not skilled driver can finish the installation, Which can save lots of installation charge;
Split Design, no need roof cutting, does not influence vehicle warranty;
Fuel Saving, it can save at least 3780 US dollars fuel cost for truck, for example;
Environment friendly, Zero Emission;
World top brand durable parts applied, which can guarantee more than 12 Years Lifetime for the whole A/C;
Unique feature: 3 cooling mode and different cooling capacity for all condition option to make balance of cooling and power consumption;
Higher Cooling to Meet the Cooling Requirement from Extremely Hot Places,even ambient temperature 55C, which already proved in India and Gulf Market;
